Balcon Solaire – Ensemble de Système Plug & Play Connecté au Réseau

Specifications:

1) 800 Watt Power Balcony System

– Deye Solar Micro Inverter 800 Watt

Input Voltage 60V
Output Voltage 230V
Output Current 2.9A/3.8A/4.8A
Output Frequency 50/60 Hz
Output Type Single
Size 212*230*40mm
Type DC/AC Inverters
Inverter Efficiency 96.5%
Certificate IEC/ UL
Warranty 10 years
Weight 3.5kg
Product name solar Micro Inverter
Maximum input DC Voltage 60V
MPPT Voltage Range 25~55V
Operating DC Voltage Range 20~60V
Max. DC Short Circuit Current 16A
Nominal Voltage / Range 230V / 184-265V
Extended Frequency / Range 45~55Hz / 55~65Hz
Power Factor >0.99
Enclosure Environmental Rating IP67

– LONGi Solar Hi-MO5m 54HIB 400W Half-Cut Full Black

Watt 400 Module type Monofacial Framed Number of cells 108 (54)
Watt/m² 205,0 Module surface (m²) 1,953
Cell Half-cut Cell Technology M10 (182mm)
Module efficiency 20,5% Temp. Coef PMAX -0,34%/K
Panel frame color Black
Dimensions 172,2 x 113,4 x 3,0 cm Weight 21,5kg
Cable length 1 200mm – MC4-EVO2 connectors
Junction box Split box – Mid

2) 600 Watt Power Balcony Solar System

– BDM-600-WiFi Micro on grid inverter (Wifi Version)

Recommended Max PV Power (Wp) 450 x 2

Max DC Open Circuit Voltage (Vdc) 60

Max DC Input Current (Adc) 14 x 2

MPPT Tracking Accuracy >99.5%

MPPT Tracking Range (Vdc) 22-55

Isc PV (absolute maximum) (Adc) 18 x 2

Peak AC Output Power (Wp) 550

Dimension: 277x132x50 mm

Grid Code Compliance:VDE -AR-N 4105*

VDE V 0126-1-1/A1

G83/2, CEI 021

AS 4777.2 & AS

4777.3,EN50438

ABNT NBR 16149/1615

Warranty: 10 years

 – 330W mono Half Cell PERC solar panel

Pmax:330W

Vmp: 28.63V Voc: 34.6V Imp 11.53A

Size : 15880*1045*35mm ; weight :16kg

Warranty: 12years product and 25years power output

PV Cable: 1.5M*2

Package: 2pcs per carton

3) 400 Watt Balcony Solar System

– LONGi Solar Hi-MO5m 54HIB 400W Half-Cut Full Black

Watt 400 Module type Monofacial Framed Number of cells 108 (54)
Watt/m² 205,0 Module surface (m²) 1,953
Cell Half-cut Cell Technology M10 (182mm)
Module efficiency 20,5% Temp. Coef PMAX -0,34%/K
Panel frame color Black
Dimensions 172,2 x 113,4 x 3,0 cm Weight 21,5kg
Cable length 1 200mm – MC4-EVO2 connectors
Junction box Split box – Mid

– Hoymiles HMS-400 Solar Microinverter

Micro inverter for connection of 1 module

Max. PV power 540 Wp

MPP voltage range 16-60V

Max. input current 14A

Rated output current 400VA

Waterproof IP67

Weight 1,75kg

Dimensions 18.2 × 16.4 × 3 cm

Warranty 12 years

Custom Solar Bracket for all balcony systems

Adjustable slop angel: 15°-30°

Special Horizontal Beam to hang on micro inverter

Material: Allumium alloy + #304 stainess steel

2pcs panels per set

Package: 1set bracket per carton

– 5m 3*1.5mm²ac cable + Fstyle Schuko and connector

250v 16A，IP44, VDE certified

– Inverter Female Protection Cap

– Power Display Socket
